| Item | Unit | 1.5T |
| Rated capacity (Load capacity) | kg | 1500 |
| Lift height) | mm | 3000 |
| Load centre distance (Load centre) | mm | 500 |
| Door trame angle | degree | 6-12° |
| Full load grade (Gradient) | degree | 10° |
| Dimensions (L*W*H) (Length Width Height) without fork | mm | 2105*1120*2158 |
| The goods fork length | mm | 920 |
| Furcation length | mm | 772 |
| Overhead guard height | mm | 1986 |
| Wheel base | mm | 1380 |
| Mast clearance (groubd clearance under mast) | mm | 102 |
| Front gauge | mm | 960 |
| Track rear | mm | 929 |
| Battery rated voltage/model (Battery(voltge/capacity) | v/Ah | 48V/300Ah |
| Net weight | ton | 3050 |
| Reference time | h | 5-8 |
| Charging time | h | 2 |
| Driving motor | Kw | 5 |
| Lifting motor | Kw | 5 |
| Motor type | | AC motor |
